get your flutter app to build itself - automated android builds
Table Of Contents
1.
Intro2.
Steps2.1.
Create the workflow file2.2.
Configure the workflow2.2.1.
Workflows Events2.2.2.
Define the Workflow Job2.2.3.
Checkout the repository2.2.4.
Setup Flutter2.2.5.
Install Dependencies2.2.6.
Build the APK2.2.7.
Upload apk to the artifacts
Intro
Lets automate the build of a flutter android app using Github Actions. By using github actions, you can save your time and resources from builds done locally.
Steps
First create a new repository on github and upload your flutter project to your github account.
If you prefer to understand the worflow, follow along. If you dont know how to do that, just press the + button on top right of github homepage, create the repository and the upload your files.
If you are a copy/paste person, fire away to this github gist link.
Create the workflow file
Now, create a folder .github/workflows in root of your project.
Create a file named build.yml in that folder. Github action will automatically pick up the configurations we will setup in a while.
Configure the workflow
Lets define the name of the github actions workflow. (be mindful of the tabs and spaces, those matter in a .yml or yaml file)
name: Flutter Android Build
Workflows Events
Now, lets set the events that will trigger the workflow. workflow_dispatch gives you a button to trigger the workflow on your will with a button.
on:
push:
branches:
- main
workflow_dispatch: # trigger on a button click
Define the Workflow Job
In GitHub Actions, jobs are used to define the tasks that need to be executed. For our workflow, we are naming the job flutter-android-build. This job will run on the latest version of Ubuntu provided by GitHub Actions.
jobs:
flutter-android-build:
runs-on: ubuntu-latest
Checkout the repository
The first step in our job is to checkout the repository. This allows GitHub Actions to access the code in your repository.
steps:
- name: Checkout Repository
uses: actions/checkout@v2
Setup Flutter
Next, we need to set up the Flutter environment. We use the subosito/flutter-action action to specify the Flutter version that we want to use, which in this case is 3.10.6.
- name: Setup Flutter
uses: subosito/flutter-action@v2
with:
flutter-version: "3.10.6"
Install Dependencies
Before building the APK, we need to install the necessary dependencies. This is done using the flutter pub get command, which fetches all the dependencies listed in your project's pubspec.yaml file.
- name: Install Dependencies
run: flutter pub get
Build the APK
With the dependencies installed, we can now build the APK. We use the flutter build apk --release command to build a release version of the APK, which is optimized for distribution.
- name: Build APK
run: flutter build apk --release
Upload apk to the artifacts
Finally, we archive the built APK using the actions/upload-artifact action. This makes the APK available as an artifact in the GitHub Actions workflow run, allowing you to download it from the GitHub interface.
- name: Archive Artifacts
uses: actions/upload-artifact@v2
with:
name: app-release
path: build/app/outputs/flutter-apk/app-release.apk
Now you can ensure an always ready-to-distribute APK without the need for manual builds!
